Plastic Automatic Loading Machine Hopper Loader with Environmental Color
1 Set / Order
MOQ
USD 400 ~ 4000 per Set
Price
Plastic Automatic Loading Machine Hopper Loader with Environmental Color
Features Gallery Product Description Request A Quote
Features
Basic Infomation
Place of Origin: Dongguan, China
Brand Name: ORSTE
Certification: CE, ISO, SGS
Model Number: OAL-S
Payment & Shipping Terms
Packaging Details: Standard Export Packing
Delivery Time: 7-15 days
Payment Terms: TT, LC, Paypal, West Union, Cash
Supply Ability: 500-3000 Sets / Year
Specifications
Material: Stainless Steel
Color: Green
Power: 0.75 ~ 7.5 KW
Application: Plastic Material Feeding
Function: Vaccum Loading
Product Description

Plastic Automatic Loading Machine Hopper Loader with Environmental Color

Plastic Loading Machine, Hopper Loader, Plastic Auto Loader, Plastic Loader, Plastic Machine



NAMING PRINCIPLE

OAL- xxS

① ②

① Orste Auto-Loader

② Motor Power (HP)

S: Separate Type

FEATURES

  • Microprocessor for ease of use and accurate control.
  • Stainless hopper receiver ensures no material contamination.
  • Motor overload protector ensures long service life of motor.
  • OAL-S loaders adopts stainless steel mesh thus avoids damage to the motor.
  • For OAL-S series, auto dust-removing device is standardly equipped which saves labor cost for cleaning of filters and expand the lifespan of the machine.
  • Complete safety protection function device, like electricity indicator, phase-reversing alarm, material shortage and motor overloading alarm.
  • Both micro-switch hopper (OVH) and photo-sensor hopper (OPH) can be directly mounted on the feed port of molding machine.

Plastic Automatic Loading Machine Hopper Loader with Environmental Color 0

FUNCTIONAL SCHEME

The control device starts the vacuum motor to take out the air in the hopper, the material valve is closed meanwhile, thus negative pressure is created. With the function of negative pressure, material in the storage tank is delivered to the hopper through material pipe. The vacuum motor stops working when the suction time comes out, the material valve is opened by material, then material falls into injection machine or other equipment.



PARAMETERS

Model Motor Power Conveying Capacity (kg/hr) Motor Type Vertical Conveying Height (m) Horizontal Distance (m) Power Hopper Capacity (L)
kw hp
OAL-1.5S 1.1 1.5 200 Carbon Brush Type 4 7.5 1ф, 230VAC, 50/60Hz 7.5
OAL-1S 0.75 1 300 Induction Type 4 8 3ф, 400VAC, 50/60Hz 7.5
OAL-2S 1.5 2 350 Induction Type 7 20 7.5
OAL-3S 2.25 3 420 Induction Type 9.5 50 7.5



Plastic Automatic Loading Machine Hopper Loader with Environmental Color 1



David Wu

Dongguan Orste Machinery Equipment Co., Ltd.

Add: Building E, South Sanlian. Rd., Luwu, Changping, Dongguan City, Guangdong Province, China. 523587

Mobile: (0086)18948606110

Skype & Email: david@orste.com

Tel: (0086)0769-82020256

Fax: (0086)0769-82026886

Web.: www.orste.com
